Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

UR35-L00AU-W-P

$751.00 NZD
$751.00 NZD
Sale Sold out
Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*

In stock
Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi
The Ursalink UR35 is a cost-effective industrial cellular router with embedded intelligent software features that are designed for multiple M2M/IoT applications. Global WCDMA and 4G LTE carrier support makes this device a must-have for operators trying to maximizing uptime.

Integrating an embedded cellular modem and dual SIM functionality, the UR35 provides 3G/4G cellular network speeds up to150 Mbps download and 50 Mbps upload, it also has 5 Ethernet ports and supports 802.11b/g/n Wi-Fi.

All of these capabilities deliver uninterrupted internet access. Easy deployment and comprehensive remote device management makes the UR35 versatile in most IoT/M2M applications.





. .

Features
  • Dual SIM cards for backup between multiple carriers
  • Ethernet, I/O, serial port and Wi-Fi for connecting end devices.
  • Ursalink DeviceHub connectivity
  • Embedded Python SDK for development
  • Rugged enclosure, optimized for DIN rail or shelf mounting
  • 3-year warranty included
Details
Product Code UR35-L00AU-W-P
CPU 528 MHz, ARM Cortex A7z
Memory 128 MB Flash, 128 MB DDR3 RAM
SIM Slots 2
Storage 1 × Micro SD
Ports 5 × RJ-45 (1 × WAN +4 × LAN (PoE PSE Optional on LAN ports)
Connectors 2 x SMA, 1 x RP-SMA
Ports 1 × RS232 + 1 × RS485 (Terminal Block)
Input Voltage 9-48 VDC (48 V power input is needed for PoE output)
Power Consumption ? 7.9W (In Non-PoE mode)
Serial Interface 1 × RS232 + 1 × RS485 (2 × RS485 Optional)
Baud Rate 300bps to 230400bps
Power Output 4 × 802.3 af/at PoE output
Ingress Protection IP30
Dimensions 135 x 103 x 45 mm (5.31 x 4.06 x 1.77 in)
Mounting Desktop, Wall or DIN Rail Mounting
Network Protocols PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIPv1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QoS, SNTP, Telnet, VLAN, SSH
Serial Port Transparent (TCP Client/Server, UDP), Modbus Gateway (Modbus RTU to Modbus TCP)
Operating Temp -40°C to +70°C (-40? to +158?) Reduced Cellular Performance Above 60°C
Storage Temp -40°C to +85°C (-40? to +185?)
Freq Bands 3G: B1/B2/B5/B8 WCDMA, 4G: B1/B2/B3/B4/B5/B7/B8/B28@FDD LTE, B40@TDD LTE
Details
Contents Power supply, Ethernet Cable, Terminal Block, Mounting Bracket, 2 x Mobile antenna, 1 x WiFi antenna, Warranty Card
