Ubiquiti UniFi U7 Outdoor WiFi 7 Access Point with Integrated Directional Super Antenna and 2.5GbE

Ubiquiti UniFi U7 Outdoor WiFi 7 Access Point with Integrated Directional Super Antenna and 2.5GbE

U7-Outdoor

$431.00 NZD
$431.00 NZD
Sale Sold out
Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*

In stock
Ubiquiti UniFi U7 Outdoor WiFi 7 Access Point with Integrated Directional Super Antenna and 2.5GbE
Ubiquiti UniFi U7 Outdoor WiFi 7 Access Point is an all-weather WiFi 7 Dual Band Access Point with 4 spatial streams, an integrated directional super antenna, and versatile mounting options. The 2.5 GbE port help deliver maximum WiFi7 speed outdoors.

PoE NOT included
Features
  • Dual Band WiFi7 with4 spatial streams
  • 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
  • Software-switchable from internal directional to included external omni antennas
  • 250+ connected devices
  • Powered using PoE+
  • 2.5 GbE uplink
  • Versatile wall and pole mounting
  • Weatherproof (outdoor exposed)
Details
Manufacturer's Code U7-Outdoor
Dimensions 170 x 208 x 54.5 mm
Weight 1.2 kg
Enclosure Material UV-stabilized polycarbonate, aluminum alloy
Mount Material Polycarbonate, SGCC steel
Pole Mount Diameter 25–60 mm on pipe outer diameter
Wind Survivability 74.6 N at 200 km/h
Weatherproofing IPX6
Networking Interface (1) 1/2.5 GbE RJ45 port
Management Interface Ethernet
Power Method PoE+
Power Supply UniFi PoE Switch
supported Voltage Range 42.5—57V DC
Maximum TX Power 2.4 GHz @ 23 dBM, 5 GHz @ 26 dBm
Antenna Gain 2.4 GHz @ Directional internal: 8 dBi/External omni: 3 dBi, 5 GHz @ Directional internal: 12.5 dBi/External omni: 4 dBi
Antenna Beamwidth 2.4 GHz @ 90°, 5Ghz @ 45°
Antennas (1) Directional internal antenna, (2) External omni antennas, (2) RP-SMA connectors for external antenna
Features Wireless Meshing, Band Steering, 802.11v BSS Transition Management, 802.11r Fast Roaming, 802.11k Radio Resource Management (RRM), Advanced Radio Management, Passpoint (Hotspot 2.0), Captive Hotspot Portal, Custom Branding Landing Page, Voucher Authentication, Payment-Based Authentication, External Portal Server support, Password Authentication, Guest Network Isolation, Private Pre-Shared Key (PPSK), WiFi Speed Limiting, Client Device Isolation, WiFi Schedules, RADIUS over TLS (RadSec), Dynamic RADIUS-assigned VLAN
Mounting Wall, ceiling, pole (Included)
Ambient Operating Temperature -30 to 60° C
Ambient Operating Humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Details
Power Supply No, sold separately
Mounting Yes, pole and wall mounts included
Warranty Standard 12 Month RTB
