Tycon Power Systems TP-VRHP-2456 Voltage Regulator 18-36VDC input 56VDC 1.25A 70W Output
Tycon Power Systems TP-VRHP-2456 Voltage Regulator 18-36VDC input, 56VDC 1.25A 70W Output.

The TP-VRHP series of DC to DC converters offer high output voltage conversion in a compact metal enclosure. They have wire terminal inputs and outputs for maximum flexibility. The units come with DIN rail adapters for DIN rail mounting.
Features
  • High Output, Short Circuit Protected
  • Metal Enclosure, DIN rail mounting
  • Industrial Temperature Operation
  • Most Models Isolated Input to Output
  • Low Voltage Disconnect
Details
Manufacturer's Product Code TP-VRHP-2456
DC Input Voltage Range +/- 18 to 36VDC
DC Voltage Output 56VDC @ 1.25A
Maximum Power 70W
Input / Output Isolation Isolated
Efficiency Better then 85%
Load / Line Reg 5% / 1%
Ripple / Noise 2% / 5%
Isolation 1500VDC Min. / 100M Ohms Min
Wire Gauge 12AWG Max
Protections Short Circuit, Overvoltage, Overload
Operating Temp -22°F to 149°F (-30°C to +65°C)
Operating Humidity 0 to 90% RH
Size 5.24 x 3 x 1.5” (133x75x38mm)
Weight 298g
Details
Included Regulator, Din Rail mount Kit
