TL-SM6110-LR - TP-Link SM6110-LR, Omada 25GBase-LR SFP28 LC Transceiver

Name: TL-SM6110-LR - TP-Link SM6110-LR, Omada 25GBase-LR SFP28 LC Transceiver
Brand: TP-LINK
SKU: TL-SM6110-LR
Price: 145.20 NZD
Availability: OutOfStock

SKU:TL-SM6110-LR

$145.20 NZD

Sale Sold out

Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*

Out of stock

Omada 25GBase-LR SFP28 LC Transceiver

Single-mode SFP+/SFP28 LC Transceiver
Hot-Pluggable with maximum flexibility
Supports Digital Diagnostic Monitoring (DDM)
Low Power Consumption no more than 1.2 W
Compatible with 10G/25G Small Form Pluggable Multi-Source Agreement (SFP+/SFP28 MSA)
Compatible with switches with 25G ports like SX6632YF; and 10G ports like SG3428X and SG3452X.

What This Product Does

The SM6110-LR is designed to extend transfer distances based on 10G/25G Ethernet connectivity. It is a 10G/25GBASE-LR high performance 1310 nm single-mode SFP+/SFP28 transceiver. It supports full duplex, 10G/25G Ethernet connections up to 10 km with 9/125µm fiber cables respectively.

PACKAGE CONTENTS
Package Contents	• SM6110-LR • Installation Guide

HARDWARE FEATURES
DDM	Yes
SFP-MSA	Yes
Hot Swappable	Yes
Dimensions ( W x D x H )	2.240.550.47 in (571412 mm)

TRANSCEIVER
Standards and Protocols	• IEEE 802.3ae, 802.3cc • SFF-8402, SFF-8431, SFF-8432, SFF-8472 • eCPRI, CPRI • TCP/IP
Wavelength	1310 nm
Power Supply	3.3V
Fiber Type	9/125um Single-Mode
Max. Cable Length	10 km
Support Data Rate	Dual Rate 25.78 Gbps and 10.31 Gbps
Connector	Duplex LC/UPC
Regulatory Compliance	CE, FCC, RoHS
Environment	• Operating Temperature: 0°C to 70°C (32°F to 158°F) • Storage Temperature: -40°C to 85°C (-40°F to 185°F) • Operating Humidity: 10% to 90% RH, Non-Condensing • Storage Humidity: 5% to 90% RH, Non-Condensing
