TC-R3105 - Tiandy 1 HDD 5ch PSE NVR TC-R3105

TC-R3105 - Tiandy 1 HDD 5ch PSE NVR TC-R3105

TC-R3105

$321.43 NZD
$321.43 NZD
Sale Sold out
Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*
  • Up to 5-ch IP camera accesses Incoming/Outgoing bandwidth:
    • 80Mbps/80Mbps S+265, H.265, S+264, H.264 video formats
  • 5-ch synchronous playback
  • Up to 10 TB capacity for each HDD
  • 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port
  • PoE interface, 4×RJ45, 10/100 Mbps self-adaptive Ethernet port

Specifications:

Input
Video Input 5-ch
Max Resolution 6MP
Two-way Audio Input 1-ch, 3.5mm
Bandwidth Income 50Mbps; Outgoing 40Mbps
Output
HDMI/VGA Output HDMI 1-ch, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800
VGA 1-ch, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800
Screen Split 1/3/4/6
Audio Output 1×RCA
Decoding
Decoding Format S 265/H.265/H.264
Recording Resolution 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Preview Capability 1×6MP, 1×5MP, 1×4MP, 1×3MP, 4×1080P, 5×720P, 5×4CIF
Synchronous Playback 1×6MP, 1×5MP, 1×4MP, 1×3MP, 4×1080P, 8×720P
Records Encryption Yes
Hard Disk
SATA 1 SATA interface for 1 HDD
Capacity Up to 10TB for each HDD
eSATA Interface N/A
Array Type N/A
External Interface
Network Interface 1xRJ45 self-adaptive 10/100 Mbps network interface
USB Interface 2xUSB 2.0
Serial Interface N/A
Alarm In/Out 0/1
Network
Protocol TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, SSL, Telnet, RTMP, NFS
System Compatibility ONVIF (PROFILE S/T/G), SDK, P2P
POE
POE Interface 4xRJ45 self-adaptive 10/100 Mbps network interface
Power per POE Port 30W
Max Current per POE Port 600mA
General
Web Version Web6
Language Simple Chinese, Traditional Chinese, English, Spanish, Korean, Italian, Turkish, Russian, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese
Operating Conditions -10℃～55℃, 10%~90% RH
Power Supply DC48V
Consumption (without HDD)  ≤20W (without HDD)
Chassis 1U
Dimensions 44×255×231mm, (1.78×10.04×9.09 inch)
Weight (without HDD) 0.59Kg (2.09lb)
