Tachyon Networks TNA-303L-65-LIB Outdoor 60 GHz PTP Link in a Box Kit
Tachyon Networks TNA-303L-65-LIB Outdoor 60 GHz PTP Link in a Box Kit
SKU:TNA-303L-65-LIB
Regular price
$695.00 NZD
Regular price
Sale price
$695.00 NZD
Shipping calculated at checkout.
* All prices exclude GST & Freight, Calculated at checkout - supply only*
In stock
Quantity
Couldn't load pickup availability
Tachyon Networks TNA-303L-65-LIB Outdoor 60 GHz PTP Link in a Box Kit
Tachyon Networks TNA-303L-65-LIB Outdoor 60 GHz PTP Link in a Box Kit.
The Tachyon Networks TNA-303L-65-LIB is a complete, pre-paired point-to-point (PTP) wireless bridge solution featuring two TNA-303L-65 units factoryconfigured for seamless, unique PTP connectivity. This "Link in a Box" kit delivers fiber-like performance with minimal setup, ideal for rapid deployment in urban, campus, or remote environments. Each kit includes two ultra-compact radios, pole mounts, PoE injectors, and all necessary cabling—ready to deploy out of the box with no additional configuration required.
Sub-7GHz offload
Because the sub-7GHz spectrum is scarce and prone to interference, the TNA-300 series models are perfect for offloading links demanding both low and high capacity, leaving the low bands for hard-to-reach places.
Deploying fiber-like service
The TNA-303L-65-LIB is perfect for delivering fiber-like services without the costs of trenching, permitting, and time delays. High speed point-to-point Use the TNA-303L-65-LIB to instantly establish secure, highcapacity PTP connections between buildings, campuses, or sites in urban environments—no pairing or alignment needed beyond basic line-of-sight setup.
High bandwidth video surveillance
The TNA-300 series units feature a proprietary TDMA scheduling protocol which is perfect for video surveillance networks requiring high-capacity upload bandwidth.
The Tachyon Networks TNA-303L-65-LIB is a complete, pre-paired point-to-point (PTP) wireless bridge solution featuring two TNA-303L-65 units factoryconfigured for seamless, unique PTP connectivity. This "Link in a Box" kit delivers fiber-like performance with minimal setup, ideal for rapid deployment in urban, campus, or remote environments. Each kit includes two ultra-compact radios, pole mounts, PoE injectors, and all necessary cabling—ready to deploy out of the box with no additional configuration required.
Sub-7GHz offload
Because the sub-7GHz spectrum is scarce and prone to interference, the TNA-300 series models are perfect for offloading links demanding both low and high capacity, leaving the low bands for hard-to-reach places.
Deploying fiber-like service
The TNA-303L-65-LIB is perfect for delivering fiber-like services without the costs of trenching, permitting, and time delays. High speed point-to-point Use the TNA-303L-65-LIB to instantly establish secure, highcapacity PTP connections between buildings, campuses, or sites in urban environments—no pairing or alignment needed beyond basic line-of-sight setup.
High bandwidth video surveillance
The TNA-300 series units feature a proprietary TDMA scheduling protocol which is perfect for video surveillance networks requiring high-capacity upload bandwidth.
Features
- Link in a Box, convenient Plug and Play solution
- Recommended for up to 1km PTP links
- Fiber-like speeds using the 60GHz band, up to 1 Gbps throughput (real world speeds) for high-capacity backhauls
- Upper-band support (Channels 1-6 / 57-71GHz)
- Ultra-compact design
- Near-Zero Interference and Easy Deployment
| Details | |
|---|---|
| Product code | TNA-303L-65-LIB-AU |
| Operating modes | Station, PTP (software configurable). |
| Max EIRP | 54dBm (regulatory dependent) |
| Link encryption | AES 128 + GCMP |
| Frequency & supported channels | Full band: 57-71 GHz: channels: 1-6, Half channels: 1-12 (see notes on support site about half channel support) |
| Channel size options | Full (2 GHz), half (1 GHz) (see notes on support site about half channel support) |
| Station scheduling | TDMA: dynamic scheduling mechanism |
| Beam steering | 8º x 8º |
| Duplexing | TDD |
| Max MTU size | 7900 b |
| Networking mode | Transparent bridge |
| VLAN capabilities | Data VLAN (in station mode) & management VLAN |
| Other features | Traffic shaping (station mode), DHCP snooping, device discovery, speedtest, and more |
| IPv4/IPv6 support | Both are supported |
| Management | Web interface, SNMP v2 & v3, SNMP traps, & RESTful API (SSH available upon request) |
| Interfaces | 1x 1G ethernet, 1x USB Type-A for aiming |
| Mount | Pole mount included |
| PoE input power | Active PoE 38-57VDC (passive injector included) |
| Max power consumption | 15W |
| Operating temperature | -30°C - 55°C |
| Base Unit dimensions & weight | Height: 13cm, Width: 12 cm, Depth: 10cm, 425 g |
| LEDs | Ethernet link status, wireless status, signal level, & power |
| Details | |
|---|---|
| Power Supply | 48V 0.5A PoE adapters included |
| Mounting Hardware | Pole mounts included |
