POWERSHIELD Mini UPS 12V DC/1.5A 18W Output

POWERSHIELD Mini UPS 12V DC/1.5A 18W Output

PSDCMIN1218

$159.50 NZD
$159.50 NZD
Sale Sold out
Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*

In stock
POWERSHIELD Mini UPS 12V DC/1.5A, 18W Output With Long Life Li-Ion Battery
POWERSHIELD Mini UPS 12V DC/1.5A, 18W Output with Long Life Li-ion Battery. Provides emergency power backup for FTTH ONT, Routers, CCTV, Alarms. Range Power Adapters The PowerShield DC Mini is designed to provide emergency power backup to all kinds of DC powered equipment including routers, modems, set-top boxes, VOIP phone systems, surveillance equipment, alarm systems and many critical telecommunications devices. DC Mini can economically provide hours of operation during power failure.
Features
  • Built-in Li-ion battery
  • Auto start when plugged in
  • Multi-colour indicator
  • Embedded Microcontroller
  • Manual power off the switch port
  • Overload, short circuit, overcharge and over-discharge protection
  • Packaged with an assortment of power connectors, including a Molex connection for the Chorus ONT
  • Provides 150min runtime for Chorus ONT
  • Dimensions: 44(W) x 79(H) x 96(D)mm
Details
Voltage Range 90V AC ~ 265V AC
Frequency 50Hz or 60Hz
Surge Protection 125J @ 4500A
DC Output Voltage 12V DC ± 5%
Maximum Power 18W (1.5A)
Battery Type Lithium-Ion Battery
Voltage 3.7V DC
Capacity 2600mAh
Typical Charging Time 3 hours recover to 90% capacity Protection
Battery Deep Discharge, Over-Charge and Short Circuit Protection.
Input/Output Fuse for Short Circuit and Overload Protection Indicators
Mult-Colour LED Display Full Battery Green - Solid
Battery Charging Green - Slow Flashing
Battery Discharging Green - Quick Flashing
Fault Red - Solid
Physical Dimensions (D x W x H) 78 x 42 x 74mm
Net Weight 280g
Typical Small Router (0.25A/3W) 150 Minutes
Typical Router (0.75A/9W) 120 Minutes
Details
Warranty Standard 12 Month RTB
