Milesight IoT

Milesight LoRaWAN AS923/AU915 WS201 Smart Fill Level Monitoring IoT Sensor

Milesight LoRaWAN AS923/AU915 WS201 Smart Fill Level Monitoring IoT Sensor

WS201-915M

$184.00 NZD
$184.00 NZD
Sale Sold out
Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*

In stock
Milesight LoRaWAN AS923/AU915 WS201 Smart Fill Level Monitoring IoT Sensor
Milesight LoRaWAN AS923/AU915 WS201 Smart Fill Level Monitoring IoT Sensor. WS201 is a wireless sensor that utilizes ToF technology to monitor the fill level of containers with high accuracy. Working with Milesight LoRaWAN® gateway and Milesight IoT Cloud, WS201 allows users to remotely monitor and manage container fill levels and status in real-time. WS201 utilizes advanced ToF (Time of Flight) technology for precise distance measurement, ensuring accurate detection of toilet paper fill levels. Additionally, it has a minimal blind zone of only 1 cm. Optimize alerts and notifications for paper supply by implementing customizable threshold levels for greater flexibility.

Perfect for smart buildings, smart city deployments or industrial use-cases.



. .

Features
  • Suitable for Diverse Toilet Paper Dispenser
  • Accurate Fill Level Monitoring with ToF Technology
  • Up to 2 Years Battery Life with One Coin Cell Battery
  • Wireless Deployment and Easy Maintenance
  • Ultra-thin body design
  • DevEUI QR code on the front for quick scanning
  • Buckle-open lid design for easy maintenance
  • Shelf Stock Level Monitoring
  • Paper Towel Level Monitoring
Details
Manufacturer's Code WS201-915M
Protocol LoRaWAN
Frequency AU915/AS923
Tx Power 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz)
Sensitivity -132dBm@300bps
Mode OTAA/ABP Class A
ToF FoV 25 °
FoV Accuracy ± 5 °
Detection Range 1 ~ 55 cm
Detection Accuracy ± 1cm
Detection Resolution 1mm (1.0 - 5.0cm), 2mm (15.0 - 35.0cm), 3mm (35.0 - 55.0cm), X = Detection Distance
Button 1 × Reset Button (Internal)
LED Indicator 1 × Indicator (Internal)
Configuration Mobile App (via NFC)
Power Supply 1 × 590mAh CR2450 Lithium Battery
Battery Life up to 2 Years
Operating Temperature -10°C ~ +60°C
Relative Humidity ~ 95% (Non-condensing)
Color & Material White, ABS + PC (Flame Retardant)
Ingress Protection IP30
Dimension 66 × 38 × 12 mm (2.60 × 1.50 × 0.47 in)
Installation On the flat surfaces with 3M tapes
Details
Contains Sensor, QSG, Mounting Screws, Fixing screw, Warranty Card
