MARS 16dBi 90deg 5GHz Dual Pol Sector Antenna

MARS 16dBi 90deg 5GHz Dual Pol Sector Antenna

ANT-144

$295.00 NZD
$295.00 NZD
Sale Sold out
Shipping calculated at checkout.

* All prices exclude GST & Freight, Calculated at checkout - supply only*

In stock
Mars 16dBi 90deg 5GHz Dual Polarized Broadband Sector Antenna MA-WD56-DP16B
The MARS 16dBi 90° 4.9GHz-6.1GHz Broadband Dual Polarized Sector Antenna (MA-WD56-DP16B) provides a cost effective solution for large scale WLL, WLAN, H-LAN, ISM, UNII, Public Safety, Municipal MESH Networks and Point-to-Multi-Point applications.
Features
  • Stable performance with 16 dBi of gain
  • Compact size allowing for easy blending with any environment
  • Tilt mount allowing for quick and easy installations
  • UV protected radome suitable for harsh environment installations
  • Antenna Mount MNT-22 included
Details
Manufacturer's Product Code MA-WD56-DP16B
Frequency Range 4.9-6.1 GHz
Gain 16 dBi
Polarisation Vertical and Horizontal
Vertical Beamwidth 8deg
Horizontal Beamwidth 90deg
Connector Type 2x N-Type Female
Dimensions 370 x 370 x 40 mm
Pole Mount Diameter 30-63mm
Details
Pole Mount Yes, MNT-22 Included
Warranty Standard 12 Month RTB
