| KIT Model |
IK-4386-MM/P/C |
| Camera Model |
IPC-T261H-MU(2.8mm) |
| NVR Model |
NVR-108MH-C/8P |
|
Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.005Lux @ (F1.6, AGC ON), B/W: 0Lux with IR |
| Shutter Speed |
1/3s to 1/100,000s |
| Slow Shutter |
Yes |
| P/N |
P/N |
| Wide Dynamic Range |
120dB |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° ~ 360°, tilt: 0° ~ 75°, rotate: 0° ~ 360° |
|
Lens |
| Lens Type |
Fixed focal lens, 2.8mm and 4mm optional |
| Focal Length & FOV |
2.8mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128° 4mm, horizontal FOV 87°, vertical FOV 46°, diagonal FOV 105° |
| Iris Type |
Fixed |
| Aperture |
F1.6 |
| Lens Mount |
M12 |
| DORI |
| DORI |
2.8mm: D: 73m, O: 29m, R: 15m, I: 7m 4mm: D: 90m, O: 35m, R: 18m, I: 9m |
| Illuminator |
| Supplement Light Type |
IR |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850nm |
| IR Range |
Up to 30m |
|
Video |
| Max. Resolution |
3200 × 1800 |
| Main Stream |
50Hz: 20fps (3200 × 1800) 25fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (1280 × 720, 960×540, 640 × 480, 640 × 360) |
| Third Stream |
50Hz: 10fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. |
| Video Compression |
Mainstream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Thirdstream: H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate |
32Kbps~16Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Mainstream supports |
| H.265+ |
Mainstream supports |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region of Interest (ROI) |
1 fixed region for mainstream and sub-stream |
| Audio |
| Audio Compression |
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio Bit Rate |
-U: 64Kbps (G.711ulaw/G.711alaw)/16Kbps (G.722.1)/16Kbps (G.726)/16Kbps to 64Kbps (AAC)/32 to 192Kbps (MP2L2)/8 to 320Kbps (MP3) |
| Audio Sampling Rate |
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
-U: Yes |
| Network |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Image |
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| SNR |
≥ 52dB |
|
Interface |
| Ethernet Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| On-board Storage |
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256GB |
| Built-in Microphone |
-U: yes |
| Hardware Reset |
Yes |
|
Event |
| Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Face Detection |
Yes |
| Deep Learning Function |
| Perimeter Protection |
Line crossing detection and intrusion detection Supports human and vehicle targets classification |
|
General |
| Linkage Method |
Upload to FTP/memory card/NAS, notify surveillance centre, trigger recording, trigger capture, send email |
| Camera Material |
Aluminium alloy body |
| Camera Dimension |
Ø127.3mm × 95.9mm |
| Package Dimension |
150mm × 150mm × 141mm |
| Camera Weight |
Approx. 600g |
| With Package Weight |
Approx. 909g |
| Storage Conditions |
-30°C ~ 60°C. Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30°C ~ 60°C. Humidity 95% or less (non-condensing) |
| Web Client Language |
33 languages - English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Anti-flicker, heartbeat, password reset via email, pixel counter |
| Firmware Version |
V5.5.113 |
| Software Reset |
Yes |
| Power Consumption and Current |
12V DC, 0.5A, max. 6W PoE (802.3af, 36V~57V), 0.20A~0.13A, max. 7.5W |
| Power Supply |
12V DC ± 25%, reverse polarity protection PoE: 802.3af, Class 3 |
| Power Interface |
Ø5.5mm coaxial power plug |
|
Approval |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
IP67 (IEC 60529-2013) |
| NVR |
| Video and Audio |
| IP video input |
8-ch Up to 8MP resolution |
| Incoming bandwidth |
80Mbps |
| Outgoing bandwidth |
80Mbps |
| HDMI output |
1-ch, 4K (4096 x 2160)/30Hz, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz |
| VGA output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Video output mode |
HDMI/VGA simultaneous output |
| CVBS output |
N/A |
| Audio output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| Decoding |
| Decoding format |
H.265+/H.265/H.264+/H.264 |
| Recording resolution |
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous playback |
8-ch |
| Capability |
1-ch@8MP (30fps)/5-ch@1080p (30fps) |
| Stream type |
Video, Video & Audio |
| Audio compression |
G.711ulaw/G.711alaw/G.722/G.726 |
|
Network |
| Remote connection |
64 |
| Network protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
|
| Network interface |
1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
| PoE |
| Interface |
8, RJ-45 10/100Mbps self-adaptive Ethernet interface |
| Power |
≤ 75W |
| Supported standard |
IEEE 802.3 af/at |
| Auxiliary Interface |
| SATA |
1 SATA interface |
| Capacity |
Up to 8TB capacity for each disk |
| USB interface |
Rear panel: 2× USB 2.0 |
| General |
| Power supply |
48V DC, 1.88A |
| Consumption(without HDD and PoE off) |
≤ 10W |
| Working temperature |
-10°C ~ 55°C |
| Working humidity |
10% to 90% |
| Dimension (W × D × H) |
265mm × 225mm × 48mm |
| Weight (without HDD) |
≤ 1kg |
| Certification |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| CE |
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
